Brother PT-P950NW Commercial Wireless Network Labeling System

SKU:

PTP950NW

Brand:

Brother Printers

Price:

$519.99

Always FREE Shipping!

Ships Same Day by 3:30 EST

1 Year Replacement Warranty!

Label More - Pay Less!

1 Year Replacement Warranty!

Ships Quickly - Speedy Delivery!

Product Description

NEW! The PT-P950NW is a complete wireless on-demand network laminating label printing solution that comes with printer, accessories, label design and print software, and a full length UL certified tape – all this for the price of just the printer! This small footprint printer produces wide, premium quality laminated labels at 360dpi print resolution, up to 32mm print height on 36mm tape, and features a built-in automatic cutter that trims a continuous "tape" to virtually any length, one at a time or as a strip of pre-cut labels. Brother laminated labels can withstand abrasion, fading, extreme temperatures, chemicals and moisture.

Replaces Brother's PT9800PCN

View Product Brochure

MAIN FEATURES:

Wi-Fi, Ethernet, USB, Host USB, Serial & Optional Bluetooth (PA-BI-002) Interfaces - Versatile Wireless and Wired Connectivity Options
Produce Premium Quality, UL Certified¹ Laminated Labels On-Demand - Virtually Eliminates the Need to Purchase Pre-Printed Labels From a Converter for Custom and Short Run Labels
Infrastructure, Adhoc and Direct Wireless Wi-Fi Communications - Connect Directly to a Windows Computer, iOS and Android Smartphone or Tablet
Larger Print Head Prints up to 32mm High on 36mm Wide Tape at 360 dpi Printing Resolution - Prints Larger, Easy to Read Labels with Smooth Curves that Help Eliminate Jagged and Pixilated Images, Including Very Small Characters and Graphics
Automatic Dual Blade Cutting Mechanism - Pre-Print Strip of Easy to Peel labels as an Alternative to Sheets and Rolls of Die Cut Labels
Future Proof Optional Accessories: Li-ion Rechargeable Battery (PA-BT-4000LI), Battery Base (PA-BB-002), Touch Panel & Display (PA-TDU-003) and Bluetooth v2.1 (PA-BI-002) - Make Printer Configuration Purchasing Decision on Current Requirements, Optional Accessories are User Installable After Deployment
Printer Includes AC Adapter and Easy to Use, Advanced Label Design Software, UL Certified Tape and Cables - Comes With Everything you Need to Help you Design and Print Premium Quality Laminated Labels
Prints Laminated Labels up to 3.1 ips - Print Speed is up to 4x Faster Than Other Brother Models and is Ideal for Work in Progress (WIP) and Higher Volume Labeling Applications
Template Mode Printing and Downloadable Databases, Optional Touch Panel & Display (PA-TDU-003) - Easy to Develop Solutions to Print Standalone, From Scanning a Barcode or Connected to an Industrial Device (ex: PLC or Tester)
Uses HGe/TZe/HSe Tape - All in One, Drop in Cartridge Design Helps Ensure you Get the Best Print Quality and Makes Replacing Media Virtually Trouble Free
Small Footprint, only 4.7" wide x 5.7" high x 7.6" deep - Ideal for Use on Crowded Bench Tops, Limited Work Space and Even on Carts
2 Year "At your side" Limited Warranty - Helps Assure Operational Confidence and Reliability, and Helps Minimize Down Time

Other Details

Model Type:

Industrial Powered Desktop Label Printer

TYPE:

Desktop

TAPE FAMILY:

TZe Series

TAPE FAMILY:

HGe Series

Tape Sizes:

1/4", 3/8", 1/2", 3/4", 1", 1.5"

Tape Technology:

TZe: up to 1-1/2"

Tape Types:

High Grade, Standard & Extra-Strength Adhesive, Flexible ID, Heat Shrink Tube, Tamper-Evident, Iron-On Fabric, Acid Free, Non-Laminated

LCD Display:

Optional Touch Panel Display (PA-TDU-003)

Backlight:

Optional Touch Panel & Display (PA-TDU-003)

Maximum Print Resolution:

360 x 720 dpi (14 x 28 dots/mm)

Maximum Print Speed:

HGe/TZe Tape: Up to 3.15 ips (80 mm/sec)

Batteries:

Optional Li-ion Rechargeable Battery (PA-BT-4000LI), Requires Optional Battery Base (PA-BB-002)

Keyboard:

Optional Touch Panel Display (PA-TDU-003)

Cutter:

Automatic (Built-In) Cutter: Full-Cut mode and Crack and Peel mode

Operation Mode:

Computer Connected (GDI Printer, Template), Connected to Host Peripheral (USB or Serial)

Printer Emulation:

Raster, ESC P, Text (Template/Form Mode)

ENERGY STAR® certified:

Yes

Control Panel:

On/Off, Feed/Cut, Wi-Fi On/Off

Power Switch:

Digital

Power Supply:

120-240VAC 60/50 Hz

AC Adapter:

AD-9100ESA (Included)

Interface:

Wi-Fi WLAN (802.11b/g/n), LAN (10/100 Base-TX), USB 2.0, Host USB, Serial (RS-232C), Optional Bluetooth v2.1 (PA-BI-002)

Near Field Communication:

None

Mobile Device Printing App:

Mobile Cable Label Tool, Mobile Transfer Express

Mobile Device Compatibility:

iOS 3.0 or Later, Android 1.6 or Later

----------------:

---------------

Microsoft Word/Outlook/Excel Add-ins:

Office 2000/2003/2007

Auto Power Off:

Yes, Programmable

Fonts:

Resident: Helsinki, Letter Gothic; P-touch Editor Software: Brother & Compatible TrueType Fonts

Font Sizes:

Scalable Fonts

Built-in Symbols:

None

Font Styles:

Regular, Bold, Shadow, Outline, Horizontal Lines, Surround, Invert

Max. Print Height:

1.26" (32 mm)

Multi-Block:

Yes

Label Length Setting:

0.16" - 39.37" (4.06mm - 999.99mm)

Auto Incrementation:

Alpha Numeric

Auto Numbering:

Alpha Numeric

Horizontal Alignment:

Left, Center, Right Justification

Vertical Printing:

Yes

Mirror Printing:

Yes

Rotate Printing:

Yes

Text Insert:

Yes

Text Framing/Fill Pattern:

Yes

Multi-copy Print:

Up to 5,000 Copies

Memory:

6MB

Memory for Transferred Data (Number):

Up to 99 Template Files

Favorites Function Key:

Optional Touch Panel & Display (PA-TDU-003)

Date/Time Stamp:

Yes

Snapper function:

Yes

Download data to unit:

Yes

Built-in Designs/Templates:

Downloadable

Download templates from Brother Cloud:

Database Printing:

Yes

Database File Compatibility:

*.accdb, *.mdb, *.xlsx, *.xlsm, *.xls, *.csv, *.txt, and Microsoft MSDE/SQL Server

Internal Fonts:

ESC P: Helsinki, Letter Gothic Template (Bitmap & Outline): Helsinki, Brussels, Letter Gothic

Internal Font Sizes:

ESC P: 21, 28, 44, 56, 88, 120 dots Template (Bitmap): 21, 28 dots Template (Outline): 35 - 380 dots (20 sizes)

Internal Font Styles:

ESC P: Bold, Italic, Underline Template: Bold, Italic, Vertical, Outline, Shadow, Outline/Shadow

Barcoding:

Yes

Barcodes (Stand-alone mode):

Linear: Code39, Code128, ITF, UPC-A/E, EAN-8/13, GS1-128 [UCC/EAN-128], Codabar (NW-7); 2D: PDF417/Micro PDF417, Data Matrix, Maxicode, QR Code/Micro QR Code

Barcodes (connected to computer):

P-touch Editor Software - Linear: Code39, Code128, ITF, UPC-A/E, EAN-8/13, GS1-128 (UCC/EAN-128), Codabar (NW-7), ISBN-2/5, POSTNET, Laser, GS1 DataBar (RSS); 2D: PDF417, QR/Micro QR Code, Data Matrix, MaxiCode, GS-1 Composite, AztecCodeC/EAN128, Pos

(PC) / (MAC) Connectivity:

Wi-Fi WLAN (802.11b/g/n), USB 2.0

Operating System:

Windows Server 2012 R2/2012/2008 R2/2008; Windows 10/8/7 (32/64bit), Windows Vista (32/64bit) Mac OS X 10.10x - 10.8x, iOS 3.0 or Later, Android 1.6 or Later

(PC) / (MAC) Available hard disk space:

50 MB

(PC) Minimum RAM memory:

512 MB

(Mac) Minimum RAM memory:

128 MB

Included Items:

One 0.94" (24mm) x 26.2' (8m) Black on White Extra-Strength Adhesive Laminated "TZe" Tape (TZeS251), USB interface cable, P-touch Editor software and printer drivers (Online), AC Adapter/Power Cord, Quick Start Guide

Housing Dimensions:

4.7" (119.4mm) x 7.6" (193mm) x 5.7" (144.8mm)

Housing Weight:

3.3 lbs (1.5 kg)

Housing Color:

Black

Warranty:

2-Year Depot Warranty (Manufacturer)

UPC Code:

0-12502-64299-2
